CABLE ACTUATED SENSOR SKD-250-4

1.215,00

Cable actuated sensor SKD-250-4

Cable Actuated Sensor up to 10200 mm (400 in) for industrial applications, with Voltage and Current (2-wire) output, and IP 67 grade protection.

Cable Actuated Sensor for distance measuring up to 10200 mm (400 in), Output 4-20 mA/10-0 VDC

Measuring range: 10200 mm (400 in)
Resolution: essentially infinite
Accuracy: 0,35% FS
Repeatibility: 0,05% FS
Input Voltage, 4…20mA Option: 8-40 VDC
Input Voltage, 0…10 VDC Option: 12-32 VDC
Output: 4-20 mA/0-10 VDC
Cycle Life: >250.000
Current Consumption (no load): 35 mA
Maximum Cable Velocity: 1,5 m/s (60 in/s)
Cable Tension: 6,4 N (23 oz.) ±40%
Working Temperature: -25°C to +85°C
Protection Grade: IP67

Data Sheet

PDF Data Sheet
