Stroke from 12.5 to 175 mm, body diameter 9,5 mm

The ELPM Linear Position Sensor has been specially designed to perform in the most arduous and extreme conditions. With stroke lengths up to 175mm. It has been proven in Motorsport applications.

Available strokes: 12.5  to 175 mm
Resolution: virtually infinitive
Temperature range: -30 to 150°C
Body diameter: 9.5 mm
Insulation resistance: >100 Mohm @ 500 Vdc
Life: 25 milions of cycles
Mounting options: sferical knot, flange and body clamps
Electrical connection: by wire
Protection Grade: IP67

Data Sheet

PDF Data Sheet
