Stroke from 25 to 250 mm, body diameter 15 mm

The ELPM Linear Position Sensor has been specially designed to perform in the most arduous and extreme conditions. With stroke lengths up to 175mm. It has been proven in Motorsport applications.

Available strokes: 25  to 250 mm
Resolution: virtually infinitive
Temperature range VLP: -40 to 100°C
VLP Temperature range: -40 to 150°C
Body diameter: 15 mm
Insulation resistance: >100 Mohm @ 500 Vdc
Life: 25 milions of cycles
Mounting options: sferical knot
Electrical connection: by wire
VLP Protection Grade: IP65
VXP Protection Grade: IP67

Data Sheet

PDF Data Sheet

Are you interested in this product?
