Gas dual axis accelerometer

By virtue of its dimensions, characteristics and compatibility with gyroscopes, this accelerometer allows the dynamic behavior of the vehicle to be interpreted and checked. Combining temperature compensation at 80°C and hightly compact size, the Texense 2 axis GAS accelerometer allows to our customers an easy installation and using with most severe conditions. Our range GAS type, have a wide range of applications: The GAS type accelerometer, with no resonance and a reduced frequency range, is ideal for measuring general vehicle behaviour. For this type the measuring range is from ± 1 g to ± 10 g.

Ranges available: ±1 g, ±2 g, ±5 g, ±10 g
Sensitivity: from 2000 to 200 mV/g
Frequency Range: from DC to 20 Hz
Power Supply: 5-16 Vdc
Supply current: 6 mA
Output: 0-5 Vdc
Dimensions: 25 x 16 x 8 mm
Weight: 15 g
Temperature range: -20°C to 100°C

Data Sheet

PDF Data Sheet
